VELDURO - PHANTOM R

🚴‍♂️ PHANTOM R – Carbon Gravel E-Bike

🔥 A high-performance electric gravel bike with a full carbon frame, weighing just 16 kg. Powered by the DJI Avinox M1 motor delivering strong torque for confident acceleration—even on demanding terrain.

📦 General Information

◦ Weight: 16 kg ◦ Maximum load capacity: 120 kg ◦ Certification: EN15194

🛠️ Frameset

◦ Frame: Carbon Fiber Gravel Frame, internal cable routing, rack-ready, tire clearance up to 50C ◦ Fork: RockShox Rudy ULT, 40 mm travel ◦ Headset: FSA No.42 / ACE-2 Alloy ◦ Rear axle: 12 × 142 mm alloy, black

⚡ Motor & Battery System

◦ Motor: DJI Avinox M1 – 250W (Boost up to 1000W), max torque 120 Nm ◦ Battery: DJI Avinox 36V 600Wh ◦ Display: DJI Avinox 2-inch OLED ◦ Controller: R&L Wireless Controllers ◦ Charger: Avinox Fast Charger 4A 168W

⚙️ Drivetrain

◦ Shifter: SRAM Rival AXS E1 ◦ Rear derailleur: SRAM Rival E1 XPLR 13-Speed (with power cable) ◦ Crankset: Avinox SL Crank, 165 mm ◦ Cassette: SRAM XG-1351 E1, 10–46T ◦ Chain: SRAM CN Rival E1 ◦ Chainring: Veldura Alloy 44T (3 mm inward)

🛑 Braking System

◦ Front brake: SRAM Rival Hydraulic Brake ◦ Front rotor: SRAM HS2 160 mm, 6-bolt ◦ Rear brake: SRAM Rival Hydraulic Brake ◦ Rear rotor: SRAM HS2 160 mm, 6-bolt

🛞 Wheels & Tires

◦ Front wheel: Easton EC70 Carbon ◦ Rear wheel: Easton EC70 Carbon Wheel (XDR) ◦ Front tire: Maxxis Rambler 700 × 45C, Tubeless ◦ Rear tire: Maxxis Rambler 700 × 45C, Tubeless

🔩 Cockpit & Parts

◦ Stem: FSA SMR Alloy (S: 70 mm, M: 80 mm, L: 90 mm, XL: 100 mm) ◦ Handlebar: Veldura Carbon, 15° flare (S/M: 420 mm, L/XL: 440 mm) ◦ Saddle: Fizik Terra Aidon X5 ◦ Seatpost: RockShox Reverb AXS XPLR 27.2, 50 mm travel, 400 mm length
