Urban Arrow - Family

🚲 Urban Arrow Family — 2026 Model Year

🔥 Easy-handling family cargo e-bike for flatter city riding — Bosch Active Line Plus (50Nm) + Enviolo CVT hub + impact-absorbing EPP cargo box The Urban Arrow Family Classic 50 (often called “Family 50”) is the entry model in the Family lineup, focused on simple, reliable daily use: school runs, shopping, and calm city commuting with a non-smart Bosch system and chain drive.

📦 General Information

◦ Model: Urban Arrow Family Classic 50 (2026) ◦ Type: Front-Loading Electric Cargo Bike (Family / Urban Commute) ◦ Intended Use: Flat city riding / daily family transport ◦ Drivetrain Type: Chain Drive ◦ E-System: Bosch non-smart system (simple & stable)

⚡ E-Bike System & Performance

◦ Motor: Bosch Active Line Plus Gen 3 (Mid-Drive) ◦ Max Torque: 50 Nm ◦ Assist Support: Up to 250% ◦ Battery: Bosch PowerPack 400Wh Li-ion (removable, frame-mounted) ◦ Real-World Range: ~50–60 km/charge ◦ Max Range (Eco, ideal conditions): Up to ~80 km ◦ Display: Bosch Purion (backlit B/W, grip-mounted) ◦ Assist Speed Limit: 25 km/h (EU) / 20 mph (US)

🦾 Frame & Dimensions

◦ Overall Length: 260 cm ◦ U-Turn Space Needed (continuous): ~5.48 m ◦ Max Width: 70 cm (front box) / 64 cm (handlebar) ◦ Max Height: 110 cm ◦ Max Height (depending on stem/handlebar adjustment): Up to 120 cm ◦ Cargo Box Size (approx.): 90 × 61 × 86 cm ◦ Frame Material: UA4.2 / UA4.4 aluminum split frame (lightweight design) ◦ Front Box Material: High-density EPP foam (impact-absorbing)

⚖️ Weight & Load Capacities

◦ Bike Weight (incl. battery): ~48–51 kg ◦ Max Gross Vehicle Weight (bike + rider + cargo): 250 kg ◦ Max Load in Front Box: 125 kg ◦ Max Rider Weight: 125 kg

⚙️ Drivetrain & Mechanical

◦ Gear Hub: Enviolo Heavy Duty / Trekking (CVT continuously variable) ◦ Shifter: Enviolo manual twist shifter ◦ Chain: KMC X1 Silver (heavy-duty) ◦ Chainguard: Hebie Chainglider (fully enclosed) ◦ Front Sprocket: Lasco 38T ◦ Rear Sprocket: Enviolo 17T flat sprocket

🛞 Wheels, Brakes & Handling

◦ Front Wheel: 20" + Schwalbe Big Ben Plus / Big Apple Plus 55mm ◦ Rear Wheel: 26" + Schwalbe Big Ben Plus / Big Apple Plus 55mm

◦ Brakes: Tektro Dorado HD-E730 Hydraulic Disc (F/R) ◦ Rotors: Tektro TR-180-17, 180 mm, 2.3 mm thickness

◦ Fork: Rigid steel steering fork (no suspension on Classic) ◦ Steering System: Mechanical dual-cable / steering rod link (durable)

🎒 Integrated Safety & Accessories

◦ Kids Seating: Bench seat + 2× adjustable 3-point harnesses ◦ Frame Lock: ABUS Shield 5650 (ART-2 certified) ◦ Kickstand: Heavy-duty dual-leg center stand ◦ Front Light: Lezyne Power E80 / Mini E65 (integrated) ◦ Rear Light: Spanninga Plateo XE (6V–36V) ◦ Saddle: Selle Royal Rio Plus (with rear grab handle)

💥 Key Highlights

◦ Bosch Active Line Plus 50Nm — smooth, easy control for flat city riding ◦ Removable 400Wh battery — 50–60 km real use (up to ~80 km Eco) ◦ Enviolo CVT hub — continuously adjustable, very comfortable for family riding ◦ EPP impact-absorbing cargo box — safer for kids + cargo ◦ Huge capacity: 250 kg total / 125 kg front box ◦ Hydraulic brakes + Schwalbe 55mm tires — stable, confidence-inspiring handling
