THOK - TP4 LTD

🚴‍♂️ THOK TP4 Ltd – Full Specifications

📦 FRAME

◦ THOK – High Module Carbon Fiber ◦ Tapered head tube 1.5” ◦ 29” geometry with flip chip ◦ Compatible with 27.5” wheels ◦ Integrated downtube battery ◦ UDH hanger technology ◦ Fully enclosed internal cable routing ◦ Fully sealed cartridge bearings ◦ Rear travel: 150 mm

📏 SIZE

◦ S / M / L / XL

⚡ MOTOR & BATTERY

◦ BOSCH Performance Line CX ◦ Power: 750W ◦ Torque: 100Nm ◦ Internal BOSCH Powertube battery 800Wh ◦ Compatible with PT600 & PT400 batteries ◦ Optional: Bosch Powermore range extender 250Wh

🖥️ DISPLAY & REMOTE

◦ BOSCH Kiox 400C display ◦ BOSCH Mini Remote

🛞 SUSPENSION

Front Fork ◦ FOX 38 Float Factory ◦ 29” Boost ◦ GRIP X2 damper ◦ HSC / LSC / HSR / LSR adjustments ◦ Travel: 160 mm ◦ Offset: 44 mm ◦ Tapered steerer 1.5”

Rear Shock ◦ FOX Float X Factory ◦ 2-position adjustment ◦ THOK custom tuning ◦ Size: 210 × 55 mm

⚙️ COCKPIT

◦ Stem: RENTHAL Apex 35 mm, 40 mm extension ◦ Headset: ACROSS BlockLock 135° ◦ Handlebar: RENTHAL Fatbar Carbon, 20 mm rise, 800 mm width ◦ Grips: RENTHAL Apex ◦ Saddle: Fizik AIDON X5, 145 mm ◦ Seatpost: FOX Transfer Factory 31.6 mm  ◦ S = 150 mm  ◦ M = 180 mm  ◦ L/XL = 210 mm

🛑 BRAKES

◦ MAGURA Gustav Pro, 4-piston ◦ Rotors:  ◦ Front: 220 mm  ◦ Rear: 203 mm

🔧 DRIVETRAIN

◦ Rear Derailleur: SRAM X0 Eagle T-Type 12-speed ◦ Shifter: SRAM AXS Pod (wireless) ◦ Cassette: SRAM XS-1275 T-Type 10–52T ◦ Chain: SRAM X0 T-Type ◦ Crankset: SRAM X0 165 mm ◦ Chainring: SRAM T-Type 34T

🛞 WHEELS & TIRES

Wheels ◦ Front: DT-Swiss HXC1501 Carbon 29” × 30 mm, 15×110 ◦ Rear: DT-Swiss HXC1501 Carbon 29” × 30 mm, 12×148, XD hub

Tires ◦ Front: SCHWALBE Albert Gravity Pro 29 × 2.5, Ultra Soft, TLR ◦ Rear: SCHWALBE Albert Gravity Pro 29 × 2.5, Soft, TLR

🦿 PEDALS

◦ RaceFace Turbine flat pedals
