RFN - ARES RALLY

🏍️ RFN - Ares Rally

High-Performance Electric Dirt Bike — Rally / Enduro Focus

🔥 Built for serious off-road, long trails, and technical terrain — with rally-grade durability, motorcycle-level brakes, and a 3-second convertible Enduro ↔ Trials design.

📦 General Information

◦ Model: RFN Ares Rally / Ares Rally Pro
◦ Type: Electric Dirt Bike (Rally / Enduro tuned)
◦ Concept: Convertible Enduro ↔ Trials (seat removes in ~3 seconds)
◦ Weight (bike only): 68 kg (without battery)
◦ Battery Weight: 15 kg
◦ Energy Regeneration: Yes (Regen braking system)

⚡ Motor & Power

◦ Motor Type: PMSM (Permanent Magnet Synchronous Motor)
◦ Cooling: Air-cooled
◦ Continuous Power: 5 kW
◦ Peak Power: 12.5 kW (upgraded vs Endurance 12 kW)
◦ Motor Torque: 58–61 Nm
◦ Max Wheel Torque: 270–305 Nm (gear dependent)

🏎️ Performance

◦ Top Speed: 75–80 km/h (depends on gearing, e.g., 13–58T)
◦ Tested Range: ~100 km @ constant 40 km/h

🔋 Battery & Charging

◦ Battery: 74V 43Ah Lithium-ion (3,182 Wh)
◦ Cells: LG Premium 21700
◦ Removable Battery: ✔ Yes (swap & charge separately)
◦ Charging Time: 2–3 hours (Quick Charge)
◦ Fast Charge: 0–80% in ~1.5–2 hours

🦾 Suspension

◦ Front Fork: Upside Down (USD)
◦ Front Travel: 200 mm
◦ Rear Shock: Single shock
◦ Adjustability: Fully adjustable / fully tunable

🦿 Wheels & Tires

◦ Front Wheel: 19"
◦ Rear Wheel: 18"
◦ Rim Material: Aluminum Series 7050 (high-strength rally grade)

🛑 Braking System

◦ Brake Type: Motorcycle-grade hydraulic system
◦ Calipers: 4-piston hydraulic (DOT4)
◦ Brake Disc: 210 mm
◦ Benefit: Superior heat management & durability vs bicycle-grade brakes

🧠 Electronics & Features

◦ Regenerative Braking: ✔ Yes (Energy Regen)
◦ Storage: 5L under-seat compartment
◦ Cargo Support: Bungee strap for securing tools & gear
◦ Special Note: Some 2024/2025 versions feature unlimited Rocket Mode (region-dependent)

🎮 Riding Modes — 4D Control System

◦ Tortoise Mode – Eco / efficiency, limited to 25 km/h
◦ Rabbit Mode – General off-road riding, ~1–2 hours use
◦ Rocket Mode – Maximum output for acceleration & steep climbs
 • Some versions limited to ~9 seconds, newer versions may be unlockable (region-dependent)
◦ Reverse Mode – Reverse gear, limited to 9 km/h

💥 Key Highlights

◦ 12.5 kW peak power — rally-level performance
◦ Motorcycle-grade 4-piston brakes + 210 mm discs
◦ 19/18 wheels with 7050 alloy rims for real off-road strength
◦ Convertible seat: Enduro ↔ Trials in ~3 seconds
◦ Removable 74V 43Ah LG battery + fast charge 0–80% in ~1.5–2h
◦ 5L under-seat storage + bungee strap
◦ Regen braking + 4 ride modes including Reverse
