NIREEK - Revenant

🚵‍♂️ Carbon Full-Suspension Plus Electric Mountain Bike — Bafang G06 Hub Motor / 48V 840Wh

🔥 Carbon full-suspension electric mountain bike with Bafang RM G06A2 250/1000W hub motor, 48V 17.5Ah Samsung battery, 27.5” Plus tires, SRAM 9-speed drivetrain, hydraulic disc brakes, thumb throttle, and 160mm front / 140mm rear suspension travel.

📦 General Information

◦ Type: Full-Suspension Plus Tire Electric Mountain Bike ◦ Frame Material: Carbon Fiber ◦ Seatpost Size: 31.6 mm ◦ Seatpost Clamp: QR / Quick Release ◦ Headset: Threadless 1-1/8 Straight ◦ Suspension Travel: 160 mm front / 140 mm rear

⚡ Motor & E-Bike System

◦ Motor: Bafang RM G06A2.250/1000.D ◦ Motor Type: Rear Hub Motor ◦ Display: Bafang DP C07 ◦ Assist Type: Cadence / Torque Sensor ◦ Assist Levels: 0–5 ◦ Walk Assist: Included ◦ Throttle: Thumb Throttle ◦ Bottom Bracket: Bafang Square Taper

🔋 Battery System

◦ Battery Cells: Samsung ◦ Battery Size: 48V 17.5Ah ◦ Battery Capacity: 840Wh

🦾 Frame & Suspension

◦ Frame: Carbon Fiber ◦ Fork: Aluminum Air Fork ◦ Fork Features: Rebound adjustment + Lockout ◦ Front Axle: 15 mm Thru Axle ◦ Front Suspension Travel: 160 mm ◦ Rear Suspension Travel: 140 mm

⚙️ Drivetrain

◦ Rear Shifter: SRAM X5 9-Speed ◦ Cassette: SRAM 9-Speed ◦ Chain: KMC E-Bike Chain ◦ Crankset: 46T Chainring with Bafang Crank Arms ◦ Drivetrain Type: 9-Speed E-Bike Setup

🛑 Braking System

◦ Brakes: SRAM Level Hydraulic Disc Brakes

🛞 Wheels & Tires

◦ Front Hub: 100 mm, 32H ◦ Rear Hub: Hub Motor ◦ Rims: 27.5" 36H Black ◦ Front Tire: 27.5×2.8" ◦ Rear Tire: 27.5×3.0"
