HIMIWAY - A3

🚲 Electric Bike Specifications: Model Himiway A3 🚲

📌 General Information

• Model: Himiway A3

• Frame Material: Front: 6061 Aluminum / Rear: A356 Steel

• Net Weight: 30.98 kg

• Max Load: 136 kg

• Recommended Rider Height: 155–183 cm

• Max Climbing Ability: 15°

• Wheel Size: 26 inches

• Waterproof Rating: IP65

• Colors: Not specified (Available in Thailand for the first time)

🔋 Battery & Charging

• Battery: LG 21700 Lithium Battery, 48V 15Ah (720Wh), Removable

• Charging Time: 5 hours (Smart US Standard Charger 48V 2.0A)

• Range: Up to 112 km per charge

🚀 Performance

• Motor: Himiway 500W Rear Hub Brushless Motor

• Max Torque: 86 Nm

• Controller: 48V/18A

• Sensor: Torque Sensor

• Throttle: Thumb Throttle

📺 Display

• Display Type: Himiway LED Display

• Functions: Speed, Battery Level, Range, Assist Level

🛞 Wheels & Tires

• Front Wheel: 26" × 1.75 rim, 13G spokes, R303F-12 12G hub, 36 holes

• Rear Wheel: 26" × 1.75 rim, 13G spokes, 500W motor hub

• Tires: Innova IA-2128, Size: 26 × 2.2, Pressure: 25–60 PSI

🛑 Braking System

• Brakes: Tektro HD-E3520 Hydraulic Disc Brakes (Front & Rear)

• Brake Rotors: 160 mm (Front & Rear)

⚙️ Drivetrain

• Gear System: Shimano Altus M310, 7-Speed

• Shifter: Not specified

• Rear Freewheel: Shimano MF-TZ500-7, 14–28T

• Crankset: J6061-T6, 170 mm with 38T Steel Chainring

• Chain: KMC Z8.3 EPT, 112 Links

🔩 Components

• Handlebar: Integrated Himiway Handlebar (Width: 680 mm, Stem: 90 mm)

• Seatpost: Himiway Flip Seatpost (27.2 × 300 mm)

• Saddle: TTZ032X

• Pedals: Aluminum

• Lights: 48V LED Front Light

• Kickstand: Adjustable, anti-tip
