EVOLVE - Diablo Carbon

🛹 EVOLVE CARBON RENEGADE – Electric Skateboard

🔥 Carbon Fibre • All-Terrain • Renegade Trucks • Dual 3500W Motors The Evolve Carbon Renegade is a tough all-terrain electric skateboard built for riders who want serious off-road capability, premium carbon fibre construction, and powerful dual-motor performance. With dual 6374 brushless sensored motors, a Samsung 50S 864Wh battery, Evolve Renegade trucks, and 175mm pneumatic tyres, this board is made for dirt, gravel, short grass, roads, and footpaths.

📦 General Information

◦ Model: Evolve Carbon Renegade ◦ Type: All-Terrain Electric Skateboard / Mountain Board Style ◦ Deck Material: Carbon Fibre ◦ Deck Length: 95 cm / 37.4 inches ◦ Wheelbase: 96.5 cm / 38 inches ◦ Remote: Evolve Phaze Remote with CNC Aluminium-Reinforced Body ◦ Max Load: 120 kg / 265 lbs ◦ Board Weight: 16.4 kg / 36 lbs

⚡ Motor & Performance

◦ Motor: Dual 6374 Custom Brushless Sensored Motors ◦ Motor Power: 3500W × 2 ◦ Total Motor Power: 7000W ◦ Top Speed: 50 km/h / 31 mph ◦ Hill Climbing: 45%+ ◦ Range: Up to 50 km / 31 miles

🔋 Battery System

◦ Battery Voltage: 43.2V ◦ Battery Capacity: 864Wh / 20Ah ◦ Battery Cells: Samsung 50S

🔌 Charging

◦ Recharge Time: 3.5–4 hours

🧠 Motor Controller / ESC

◦ ESC: EFOC 2 ◦ Controller Type: Evolve Custom 50V, 200A Dual-Motor Driver ◦ Motor Control: FOC Motor Commutation ◦ Connectivity: Bluetooth Connection

🛞 Wheels & Bearings

◦ Wheels: Evolve 175mm / 7-Inch Pneumatic Tyres ◦ Hubs: Evolve All-Terrain Hubs ◦ Bearings: Evolve Stainless Steel Ball Bearings
