BIANCHI - E-OMNIA T-TPYE (STEP-THROUGH)

🚴‍♂️ BIANCHI E-OMNIA T-TYPE (STEP THROUGH) (2026 Model Year)

🔥 Easy step-through touring / daily utility e-bike — powerful 90Nm OLI motor + premium integrated rear rack. The BIANCHI E-OMNIA T-TYPE Step Through (2026) is a trekking/urban utility e-bike designed for everyday riding with an easy on/off step-through frame. It combines the OLI EDGE motor (90 Nm) with a large 630Wh battery, plus a full set of practical accessories including integrated lights, fenders, kickstand, and an integrated rear carrier built into the frame.

📦 General Information

◦ Model: BIANCHI E-OMNIA T-TYPE (STEP THROUGH) (2026) ◦ Type: Trekking / Urban Utility e-Bike (Step-Through Frame) ◦ Frame: e-OMNIA T-Type ST ALU ◦ Sizes: 43 / 48 / 53 ◦ Rear Dropouts: 12×148 mm Thru-Axle (special dropout for external derailleur) ◦ Brake Mount: Post Mount 180 ◦ Frame Lock Compatible: Yes ◦ Rear Carrier: Integrated into the frame design

⚡ Motor & Battery

◦ Motor: OLI EDGE ◦ Max Torque: 90 Nm ◦ Battery: OLI 630Wh

🦾 Frame & Suspension

◦ Fork: Suntour XCM34-Boost NLO DS 29" ◦ Fork Travel: 120 mm ◦ Headset: FSA NO.55R/558 1.5

⚙️ Drivetrain

◦ Shifter: Shimano SL-M4100-R (10-speed) ◦ Rear Derailleur: Shimano RD-M4120 (10-speed) ◦ Crankset: FSA E-Bike 170 mm, 38T ◦ Bottom Bracket: Included in the drive unit ◦ Chain: KMC e10S NPBK ◦ Cassette: 11–42T

🛑 Braking System

◦ Brakes: Shimano MT-200 (2-piston), mineral oil ◦ Brake Levers: Shimano BL-MT200 ◦ Rotors: 180 mm, Center Lock

🦿 Wheels & Tires

◦ Wheels: Velomann Tubeless Ready 29" (25-622) ◦ Tires: Vittoria e-Randonneur 50-622

🧩 Cockpit

◦ Stem: Velomann Ø31.8 ◦ Stem Length: 90 mm (SM) / 110 mm (MD, LG) ◦ Handlebar: Velomann Ø31.8 / 680 mm ◦ Bar Shape: Rise 20 mm / Sweep 15° ◦ Grips: Hermans Grip 130

🪑 Saddle & Seatpost

◦ Seatpost: Velomann 31.6×350 (Suspension Seatpost) ◦ Saddle: Velomann 285×187 mm (Steel rail)

🧰 Accessories

◦ Pedals: VP VPE-889P (with reflectors) ◦ Fenders: SKS A65R ◦ Kickstand: Velomann (Load 35 kg) ◦ Rear Carrier: Integrated into the frame design ◦ Front Light: Spanninga Custom Integrated Light (40 lux) ◦ Rear Light: Spanninga Custom Integrated Light

💥 Key Highlights

◦ Step-through frame for easy mounting and daily convenience ◦ OLI EDGE 90 Nm motor — strong support for hills and carrying loads ◦ 630Wh battery — ideal for touring and consistent daily use ◦ Integrated rear carrier — clean look, strong structure, real cargo utility ◦ 29” tubeless-ready wheels + Vittoria e-Randonneur tires — durable, efficient for city and touring ◦ Factory-equipped with integrated lights, fenders, and kickstand — ready to ride immediately
