BIANCHI - E-OLTRE (DURAACE)

🚴‍♂️ BIANCHI E-OLTRE (DURA-ACE Di2) (2026 Model Year)

🔥 Flagship Aero E-Road — ultra-clean full internal routing + Shimano Dura-Ace Di2 electronic drivetrain.
The BIANCHI E-OLTRE (2026) is a high-end aero e-road bike with a fully integrated carbon frameset (ICR), Mahle X30 assist (40 Nm / 250W) for a smooth and natural ride feel, plus 50 mm carbon wheels and Vittoria tubeless-ready tires for speed and comfort in one complete build.

📦 General Information

◦ Model: BIANCHI E-OLTRE (Dura-Ace Di2) (2026)
◦ Type: E-Road / Aero e-Road Bike
◦ Frame: Oltre e-road carbon (fully internal cable routing / ICR)
◦ Drivetrain Compatibility: Mechanical & Electronic supported
◦ Bottom Bracket: BB Pressfit
◦ Brake Standard: Disc Brake Flat Mount
◦ Rear OLD: 135 mm
◦ Sizes: 47 / 50 / 53 / 55 / 57 / 59 / 61

⚡ Motor, Display & Battery

◦ Motor: Mahle X30 Drive Unit
◦ Max Torque: 40 Nm
◦ Motor Power: 250W
◦ Control Unit: iWoc ONE head unit
◦ E-Shifters Support: Yes
◦ Battery: Mahle iX250w Battery Pack

🦾 Frameset

◦ Frame: Oltre e-road carbon
◦ Fork: Full carbon aero road ICR (Integrated head)
◦ Brake Mount: Disc brake flat mount
◦ Front Axle: 12×100 Thru Axle
◦ Headset: Acros / FSA (ICR internal routing system)

⚙️ Drivetrain

◦ Shifters: Shimano Dura-Ace Di2 12-speed
◦ Front Derailleur: Shimano Dura-Ace Di2 FD-R9250
◦ Rear Derailleur: Shimano Dura-Ace Di2 RD-R9250
◦ Crankset: Shimano Dura-Ace FC-R9200 (Hollowtech II) 52/36T
◦ Crank Length:
◦ 47 / 50 / 53: 170 mm
◦ 55 / 57 / 59: 172.5 mm
◦ 61: 175 mm
◦ Torque Sensor / BB: Mahle torque sensor BB
◦ Chain: Shimano Ultegra 12-speed
◦ Cassette: Shimano Ultegra 12-speed 11–34T
◦ Sprocket Steps: 11-12-13-14-15-17-19-21-24-27-30-34T

🛑 Braking System

◦ Brake System: Included in the shifter (integrated with levers)
◦ Front Rotor: Shimano MT800 Centerlock 160 mm
◦ Rear Rotor: Shimano RT86 6-bolt 160 mm

🦿 Wheels & Tires

◦ Wheelset: Velomann Plutonium (Carbon)
◦ Wheel Size: 21-622
◦ Rim Profile: 50 mm
◦ Spoke Count: Front 24H / Rear 32H
◦ Tubeless: Tubeless Ready
◦ Tires: Vittoria Rubino V 28-622 TLR, G2.0, 100TPI

🧩 Cockpit

◦ Bar/Stem: Reparto Corse Integrated Handlebar (Carbon) for Acros ICR
◦ Bar Geometry: Drop 125 mm / Reach 80 mm
◦ Stem Length / Bar Width (Ext/Width):
◦ 90 / 380 (Size 47)
◦ 100 / 400 (Size 50–53)
◦ 110 / 400 (Size 55–57)
◦ 120 / 420 (Size 59–61)
◦ Bar Tape: Bianchi Arrow Premium 2.5 mm (All Black)

🪑 Seatpost & Saddle

◦ Seatpost Clamp: Included in the frame
◦ Seatpost: Full carbon aero shape
◦ Clamp System: Special clamp + adjustable/reversible aluminum head (±35 mm)
◦ Seatpost Length:
◦ 300 mm (Size 47–50)
◦ 350 mm (Size 53–61)
◦ Saddle: Velomann Mitora Lite 139 (139×250 mm)
◦ Saddle Rails: Carbon rails 7×9.1 mm

💥 Key Highlights

◦ Mahle X30 (40 Nm) — natural, smooth, quiet assistance
◦ Aero carbon frame with full internal routing (ICR) — clean pro-level look
◦ Shimano Dura-Ace Di2 12-speed — fast, precise electronic shifting
◦ 50 mm carbon wheels (tubeless ready) — strong speed retention
◦ Vittoria Rubino V TLR 100TPI — reliable grip and comfort for long rides
