AVENTON - Level 4 REC

🚴‍♂️ Aventon Level 4 REC (2026 Model Year)

🔥 Urban / Commuter e-Bike — Powerful, Smart, and Ready for Daily Use

The Aventon Level 4 REC (2026) is a feature-packed urban commuter e-bike designed for everyday riding, combining strong performance, long range, and advanced smart technology for a modern riding experience.

📦 General Information

◦ Model: Aventon Level 4 REC (2026)
◦ Type: Urban / Commuter Electric Bike

◦ Bike Weight: 68.5 lbs (approx. 31 kg)
◦ Max Payload: 300 lbs (approx. 136 kg)

◦ Recommended Rider Height:
   • Regular: 5'3" – 5'10"
   • Large: 5'10" – 6'4"

◦ Water Resistance:
   • Bike: IPX5
   • Components: IPX6

◦ Range: Up to 75 miles (approx. 120 km)

◦ Safety Certification: UL 2849

⚡ Motor & Battery

◦ Motor: Rear Hub Motor

◦ Power:
   • 750W Nominal
   • 1188W Peak
   • 1440W Boost Mode

◦ Torque:
   • 80Nm Standard
   • 96Nm Boost Mode

◦ Pedal Assist:
   • Cadence + Torque Sensor Compatible

◦ Throttle: Yes

◦ Speed Class:
   • Class 2 (Convertible to Class 3)

🔋 Battery

◦ Battery Capacity: 36V 20Ah (733Wh)
◦ Cell Type: LG 21700 Cells
◦ Battery Weight: 8.7 lbs
◦ Removable: Yes

◦ Charging Time: ~5 hours
◦ Charger: 42V 4A

📟 Display & Smart System

◦ Display: Aventon A280 Display

◦ Smart Features:

   • Regenerative Braking
   • Ride Tune Customization
   • 4G + GPS Tracking
   • Anti-theft + E-Lock
   • Unusual Activity Detection
   • Hold Mode
   • Remote Notifications

🪶 Frame

◦ Frame Material: 6061 Aluminum

◦ Rear Spacing: 148 mm
◦ Fork Spacing: 100 mm

🛞 Suspension

◦ Front Fork: Coil Spring Suspension

   • Travel: 80 mm
   • Adjustable Preload
   • Lockout Function

🛑 Braking System

◦ Front Brake: Tektro HD-E3520 Hydraulic Disc
   • 2-Piston
   • E-Cutoff

◦ Rear Brake: Tektro HD-E3520 Hydraulic Disc
   • 2-Piston
   • E-Cutoff

◦ Rotor Size:
   • 180 mm Front / Rear

◦ Additional System:
   • Regenerative Braking

⚙️ Drivetrain

◦ Gearing: Shimano 8-Speed

◦ Rear Derailleur: Shimano Altus RD-M310
◦ Shifter: Shimano Trigger Shifter
◦ Cassette: 12–32T

◦ Chainring: 48T
◦ Crank Length: 165 mm

◦ Bottom Bracket:
   • Integrated Torque Sensor

🛞 Wheels & Tires

◦ Wheels: 27.5" Double-Wall Aluminum

◦ Front Hub: 15×100 mm Thru-Axle
◦ Rear Hub: Integrated Hub Motor

◦ Tires: Kenda Kwick Seven-5 Sport
   • Size: 27.5" × 2.2"

🧩 Cockpit & Components

◦ Handlebar: Aluminum 680 mm
◦ Stem: Adjustable Stem (90°)
◦ Grips: Aventon Lock-on

◦ Saddle: Aventon Saddle

◦ Seatpost: Suspension Seatpost
   • Travel: 50 mm
   • Size: 30.9 mm

🎁 Accessories

◦ Integrated Front & Rear Lights
◦ Full Fenders
◦ Rear Cargo Rack

⚖️ Key Highlights

◦ 750W motor with up to 96Nm torque (Boost Mode)
◦ 733Wh battery with up to 120 km range
◦ Supports both cadence + torque sensors
◦ Regenerative braking system for energy recovery
◦ Advanced smart features (GPS / 4G / Anti-theft / App)
◦ 80mm front suspension with lockout
◦ Hydraulic brakes with E-Cutoff safety system
◦ Comes fully equipped with rack, fenders, and lights
◦ Perfect for commuting, daily riding, and light touring
