🚵‍♂️ Aventon Aventure M eBike — 2026 Model Year

🔥 Mid-Drive Fat Tire Beast — high torque, true all-terrain performance, and built to carry serious weight with a 400 lbs total payload capacity.

📦 General Information

◦ Model: Aventon Aventure M eBike (2026) ◦ Type: All-Terrain / Fat Tire Mid-Drive eBike ◦ Intended Use: All-Terrain Performance ◦ Bike Weight: 73 lbs (≈ 33.1 kg) ◦ Max Total Load Capacity: 400 lbs (≈ 181 kg)

◦ Recommended Rider Height: ◦ Size R: 5'3" – 5'10" ◦ Size L: 5'10" – 6'4"

◦ eBike Classification: ◦ Factory: Class 1 ◦ Convertible: Class 2 (optional throttle) ◦ Convertible: Class 3

◦ Maximum Range: Up to 85 miles (≈ 136 km)

◦ Waterproof Rating: ◦ Bike System: IPX6 ◦ Motor: IP67

◦ Safety Standards: UL 2271 / UL 2849

⚡ Motor & Battery System

◦ Motor: Aventon A100 Mid-Drive Motor ◦ Voltage: 36V ◦ Continuous Power: 250W ◦ Peak Power: 750W ◦ Torque: 100 Nm ◦ Motor Waterproof Rating: IP67

◦ Battery: Removable Internal Lithium-Ion Battery ◦ Capacity: 36V 20Ah ◦ Energy: 733Wh ◦ Cells: LG 21700 Cells ◦ Battery Weight: 8.7 lbs

◦ Controller: Integrated in motor ◦ Pedal Sensor: Double-sided torque sensor ◦ Throttle Compatibility: Supports optional aftermarket throttle installation

◦ Charger: 42V 4A (36V system) ◦ Charging Time: 0–100% ≈ 5 hours

🖥️ Display & Lighting

◦ Display: Aventon BC280 ◦ Displays: Battery / Speed / Assist Mode + full ride data

◦ Lighting: ◦ Integrated Front Light: Yes ◦ Integrated Rear Light: Yes ◦ Brake Light Function: No

🦾 Frame

◦ Frame Material: 6061 Aluminum Alloy ◦ Rear Hub Spacing: 190 mm ◦ Fork Spacing: 135 mm

🛞 Suspension System

◦ Front Fork: Aventon / Zoom Suspension Fork ◦ Travel: 80 mm ◦ Lockout: Yes

🛑 Braking System

◦ Front Brake: SRAM DB4 Hydraulic Disc (no motor cutoff) ◦ Rear Brake: SRAM DB4 Hydraulic Disc (no motor cutoff) ◦ Front Rotor: SRAM G2 200 mm (6-bolt) ◦ Rear Rotor: SRAM G2 180 mm (6-bolt)

⚙️ Drivetrain

◦ Rear Derailleur: Shimano CUES 10-Speed ◦ Shifter: E-Shifter ◦ Chain: 9/10/11-speed compatible, 124L ◦ Cassette: Shimano CUES 10-Speed 11–39T ◦ Chainring: 44T ◦ Crankset: Aventon 170 mm ISIS splined ◦ Pedals: 9/16" Alloy Platform

🦿 Wheels & Tires

◦ Front Wheel: 26" Aluminum Fat Tire Rim ◦ 36H / Thru Axle / Schrader valve

◦ Rear Wheel: 26" Aluminum Fat Tire Rim ◦ 36H / Thru Axle / Schrader valve

◦ Tires: Inova 26 × 4.0 Puncture Resistant ◦ Benefit: Excellent traction on sand, grass, gravel, and rough surfaces

🧩 Cockpit & Components

◦ Saddle: Aventon Saddle ◦ Seatpost: Aventon Suspension Seatpost ◦ Diameter: 30.9 mm ◦ Length: 350 mm ◦ Travel: 50 mm ◦ Seatpost Clamp: 34.9 mm

◦ Handlebars: Aluminum ◦ Clamp Diameter: 31.8 mm ◦ Width: 720 mm

◦ Grips: Aventon Lock-On Grips ◦ Headset: Sealed Bearing H887 Peilin

🎁 Included Accessories

◦ Kickstand: Included ◦ Rear Rack: Included ◦ Fenders: Included

💥 Key Highlights

◦ 100 Nm mid-drive motor with natural torque-sensor ride feel ◦ 733Wh LG battery + up to 136 km range ◦ 26×4.0 fat tires for true all-terrain traction ◦ 400 lbs total payload capacity for utility + adventure ◦ Front suspension + suspension seatpost for comfort on rough roads ◦ Factory-ready setup: rack + fenders + kickstand included ◦ Convertible class options + optional throttle compatibility
