AVENTON - Aventure 3 Step Through

🚲 AVENTON - Aventure 3 Step Through 🚲

📌 General Information

• Model: Aventure 3 Step Through

• Bike Weight: 77 lbs (35 kg)

• Max Payload: 400 lbs (181 kg)

• Recommended Rider Height:
  • Size R: 150–170 cm
  • Size L: 170–185 cm

• Ebike Class: Class 2 (Upgradeable to Class 3)

• Water Resistance Rating: IPX5

• Best Use: All-terrain / adventure

• Battery Safety Certification: UL 2271

• Bike Safety Certification: UL 2849

• Max Range: Up to 105 km (dependent on usage)

🛠️ Frameset

• Frame: 6061 Aluminum with Gravity Cast front triangle

• Style: Step-Through

• Front Fork: Aventon/Zoom, 80mm travel, suspension fork with lockout

• Rear Dropout Spacing: 190 mm

• Front Dropout Spacing: 135 mm

🛞 Wheelset

• Front Wheel: 26", 36-hole aluminum rim, bolt-on hub, Schrader valve

• Rear Wheel: 26", 36-hole motor hub, bolt-on, Schrader valve

• Tires: Inova 26x4.0, puncture-resistant

⚙️ Drivetrain

• Rear Derailleur: Shimano Altus 8-speed

• Shifter: Shimano 8-speed Trigger

• Chain: 7/8-Speed, 118 links

• Cassette: Shimano CS HG200-8, 12-32T

• Chainring: 48T

• Crankset: 3-piece, 170 mm

• Bottom Bracket: Square Taper 100x177 mm with torque sensor

• Pedals: Aluminum 9/16"

🛑 Brakes

• Front & Rear Brakes: Tektro HD-E3520 Hydraulic Disc with EJ1 quick disconnect

• Rotors: 180 mm, 6-bolt (Tektro)

🔧 Cockpit & Accessories

• Saddle: Aventon Saddle

• Seatpost: Suspension Ø30.9 mm, 350 mm long, 50 mm travel

• Seatpost Clamp: Ø34.9 mm

• Handlebar: Aluminum Ø31.8 mm, 680 mm wide

• Grips: Aventon Lock-on

• Headset: Cartridge bearing H887 (28.65656 mm)

• Included Accessories:
  • Rear-mounted kickstand
  • Rear cargo rack
  • Full front & rear fenders

🔋 Battery & Electrical System

• Motor: 36V 750W Hub Drive (peak 1188W), 80 Nm torque

• Battery: Removable 36V 20Ah (733Wh) Lithium-ion, LG 21700 cells

• Battery Weight: 3.95 kg

• Display: Aventon BC280

• Controller: 36V / 33A

• Sensor: Dual-sided torque sensor (bottom bracket mounted)

• Throttle: Left-side integrated thumb throttle

• Charger: 42V / 4A output, full charge in ~5 hours

• Lights: Integrated front & rear LED lights

• Speed Limit: Class 2 (~32 km/h)
