AVENTION - Level 3 Step Through Commuter

🚲 AVENTION - Level 3 Step Through Commuter 🚲

📌 General Information

• Model: Level 3 Step-Through Commuter Ebike

• Net Weight: 67 lbs (approx. 30.4 kg)

• Max Payload: 300 lbs (approx. 136 kg)

• Box Dimensions: 61" x 13" x 34"

• Rider Height Range: 150 – 185 cm

• Water Resistance: IPX5

• Ebike Classification: Class 2 (Adjustable to Class 3 per local law)

• Use Case: City commuting

• Max Range: Up to 112 km

• Pedal Assist Levels: 3 levels (Ride Tune adjustable)

• Battery Safety Standard: UL 2271

• Bike Safety Certification: UL 2849

🛠️ Frameset

• Frame: 6061 Aluminum (Gravity Cast Front Triangle)

• Fork: Aventon Suspension Fork – Coil spring, 80mm travel, lockout, 15x100mm thru-axle, 43mm offset

• Rear Hub Spacing: 142 mm

• Front Hub Spacing: 110 mm

• Frame Style: Step-Through

🛞 Wheels & Tires

• Front Wheel: 27.5", 36H, double-wall aluminum rim, Schrader valve, thru-axle

• Rear Wheel: 27.5", 36H, bolt-on motor hub, Schrader valve

• Tires: Kenda Kwick Seven-5 Sport, 27.5 x 2.20

⚙️ Drivetrain

• Rear Derailleur: Shimano Altus RD-M310

• Shifter: Shimano SL-M315-8R (8-speed)

• Chain: 7/8-speed, 120 links

• Cassette: Shimano CS HG200-8, 12-32T (8-speed)

• Chainring: 48T, BCD 104

• Crank Arm: 3-piece, 170mm

• Bottom Bracket: Square taper, sealed, dual-sided torque sensor (83mm x 158.5mm)

• Pedals: 9/16" composite platform

🛑 Brakes

• Front Brake: Magura AT-2 Hydraulic Disc

• Rear Brake: Magura AT-2 Hydraulic Disc

• Front Rotor: Magura MDR-A 180mm, 6-bolt

• Rear Rotor: Magura MDR-A 180mm, 6-bolt

🧩 Cockpit

• Saddle: Aventon Saddle

• Seatpost: Aventon Suspension Seatpost Ø30.9 mm, 350 mm length, 50 mm travel

• Seatpost Clamp: Ø34.9 mm

• Handlebar: Aluminum Ø31.8 mm, 680 mm width

• Grips: Aventon Lock-on Grips

• Headset: Sealed bearing

📦 Included Accessories

• Rear Rack: Supports up to 60 lbs (27 kg)

🔋 Battery & Electrical System

• Motor: 36V, 500W (continuous), 864W (peak)

• Torque: 60 Nm

• Battery: 36V 20Ah (733Wh) Lithium-ion, removable, LG 21700 cells

• Battery Weight: 3.95 kg

• Display: Aventon BC280

• Controller: 36V / 24A

• Throttle: Left-mounted

• Sensor: Dual-sided torque sensor (bottom bracket mounted)

• Charger: 42V / 4A (5-hour charge time)

• Lights: Built-in front and rear lights

• Top Speed: Class 2 standard (adjustable to Class 3)
