AMFLOW - PR Carbon Pro

🏍️ AMFLOW PR Carbon Pro — 2026 Model Year

🔥 Pro-spec build with Avinox M2S (150 N·m peak) + 12A fast charging + Magura Gustav Pro 4-piston brakes — upgraded power, control, and stopping confidence for serious riding.

📦 General Information ◦ Model: AMFLOW PR Carbon Pro (2026) ◦ Frame: Amflow PR Carbon Pro Frame ◦ Color: Basalt Grey ◦ Adjustable Geometry: Up to 40 configurations ◦ Rear Wheel Compatibility: 27.5" and 29"

⚡ E-Bike System ◦ Drive Unit: Avinox M2S Drive Unit ◦ Torque: 130 N·m nominal / 150 N·m peak ◦ Display: Avinox 2-inch OLED Control Display ◦ Battery: Avinox Removable Battery 800Wh ◦ Controllers: Avinox Wireless Controllers (Left/Right) ◦ Charger: Avinox Fast Charger 12A / 508W

🦾 Frame & Suspension ◦ Rear Shock: FOX Float X Performance (MY 2027) ◦ Spec: 2-position lever, custom tune, LSR adjustment, 210×55mm, air shock ◦ Front Fork: FOX 36 Performance (MY 2027) ◦ Travel: 160mm ◦ Damper: GRIP ◦ Adjustments: Sweep / LSR ◦ Axle: 15×110mm ◦ Offset: 44mm

⚙️ Drivetrain ◦ Rear Derailleur: SRAM S1000 Eagle Transmission Derailleur ◦ Shifter: SRAM AXS Pod Controller ◦ Chainring: SRAM Eagle Transmission DM Chainring 38T (for Avinox) ◦ Cassette: SRAM XS-1270 10–52T ◦ Chain: SRAM Eagle 70 Transmission Flattop Chain ◦ Power Cable: Avinox M2 Series Electronic Rear Derailleur Power Cable ◦ Crankset: Avinox SL Crank ◦ Crank Length: 155mm (M/L) / 160mm (XL/XXL)

🛑 Braking System ◦ Brakes: Magura Gustav Pro Hydraulic Disc Brake (4-piston) ◦ Rotors: Magura Sensor Rotor 203mm (2.5mm thickness)

🦿 Wheels & Tires ◦ Wheelset: Amflow XMA-30 Mullet Version ◦ Front Rim: Alloy 29", 30mm, 32H, Tubeless Ready ◦ Rear Rim: Alloy 27.5", 30mm, 32H, Tubeless Ready ◦ Spokes: SAPIM E-Light ◦ Front Hub: Alloy, 2 sealed bearings, 15×110, 32H, 6-bolt ◦ Rear Hub: Alloy, 4 sealed bearings, 12×148, 32H, 6-bolt, 4 pawls 36T, HG ◦ Front Tire: Schwalbe Magic Mary Radial 29×2.5 (Ultra Soft, Tubeless Ready) ◦ Rear Tire: Schwalbe Albert Radial 27.5×2.5 (Addix Soft, Tubeless Ready)

🧩 Cockpit & Components ◦ Handlebar: Amflow Enduro Alloy Handlebar ◦ Spec: 40mm rise / 800mm width / Ø35mm ◦ Sweep: 5° upsweep / 9° backsweep ◦ Grips: Amflow Enduro Grip 2 Lock-on Grips ◦ Stem: Amflow Mountain Bike Split Stem ◦ Spec: 35mm length / Ø35mm clamp ◦ Saddle: Amflow Mountain Saddle ◦ Dropper Post Shim: 0 / 5 / 10 / 15 / 20 / 25mm adjustment ◦ Dropper Travel: 190mm (M) / 210mm (L/XL) / 230mm (XXL)

🎁 In the Box ◦ Avinox Front Light ◦ Amflow Bottle Cage ◦ Three Geometry Adjustment Systems (0.5°/1° headset cups, chainstay flip-chip) ◦ Removable Battery Keys × 2 ◦ 5/10mm Dropper Travel Reducing Spacer ◦ Quick Start Guide ◦ Rear Light ◦ Torque Wrench ◦ Clear Frame Protection Film ◦ Shock Pump

💥 Key Highlights ◦ Avinox M2S with 150 N·m peak torque + removable 800Wh battery ◦ 12A / 508W fast charger for quicker turnaround between rides ◦ Magura Gustav Pro 4-piston + 203mm (2.5mm) rotors — powerful braking ◦ Up to 40 geometry configurations + rear wheel compatibility 27.5/29
